Description:

The MT2E Series provides customers with value and affordable horsepower. This series not only promotes a variety of horsepower’s, but also boast numerous features and implements that can make this series a perfect fit for many applications.

Specifications:

Engine

• Type: 3-Cylinder, CRDI, Water-Cooled, Diesel, Turbocharged (TC)
• Model: L3C19-T
• Engine HP (Gross): 40 HP
• PTO HP: 32.0 HP
• Rated Speed: 2,600 RPM
• Displacement: 114.7 cu in
• Fuel Tank Capacity: 7.4 gallons
• Alternator: 12V – 70 Amps

Drive Train

• Transmission: Hydrostatic Transmission (HST)
• Number of Speeds: 3 Ranges
• Brakes: Wet, Multi-Disc
• Steering: Hydrostatic Power Steering

PTO

• Type: Independent
• Rear PTO RPM: 540 (Standard)
• Mid PTO RPM: 2,000 (Option)

Hydraulic System

• Implement Pump Flow: 8.2 gpm
• Steering Pump Flow: 5.5 gpm
• Total Flow: 13.7 gpm
• 3-Point Hitch Category: CAT 1
• Hitch Lift Capacity: 1,808 lbs
• Lift Control Type: Manual

Dimensions

• Overall Length (Frame to Link): 121 inches
• Wheelbase: 69 inches
• Overall Width with Tires: 54 inches
• Height to Top of ROPS: 88 inches

Tire Size

• Ag (Front / Rear): 7 – 14 / 11.2 – 24
• Industrial (Front / Rear): 25 x 8.5 – 14 / 43 x 16 – 20
• Turf (Front / Rear): 25 x 8.5 – 14 / 41 x 14 – 20

Weight

• Total Weight without Ballast: 2,884 lbs
