Description:
The MT2E Series provides customers with value and affordable horsepower. This series not only promotes a variety of horsepower’s, but also boast numerous features and implements that can make this series a perfect fit for many applications.
Specifications:
Engine
- Type: 3-cylinder, CRDI, liquid-cooled, Diesel, Naturally Aspirated (NA)
- Model (Tier 4): L3C19-D2
- Engine HP (Gross): 35 HP
- PTO HP: 28 HP
- Rated Speed: 2,600 RPM
- Displacement: 114.7 cu.in.
- Fuel Tank Capacity: 7.4 gallons
- Alternator: 12V, 70A
Drive Train
- Transmission: Hydrostatic (HST)
- Speeds: 3 Ranges
- Brakes: Wet, Multi-disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear RPM: 540 (Standard)
- Mid RPM: 2,000 (Optional)
Hydraulic System
- Control System: Position
- Pump Capacities:
- Implement Pump: 8.2 gpm
- Steering Pump: 5.5 gpm
- Total Flow: 13.7 gpm
- 3-Point Hitch Category: CAT 1
- Hitch Lift Capacity: 1,808 lbs
- Remote Valves: Optional
Dimensions
- Overall Length (Frame to Link): 121 in.
- Wheelbase: 69 in.
- Overall Width (with Tires): 54 in.
- Height to Top of ROPS: 88 in.
Tire Sizes
- Ag Tires (Front / Rear): 7 – 14 / 11.2 – 24
- Industrial Tires (Front / Rear): 25 x 8.5 – 14 / 43 x 16 – 20
- Turf Tires (Front / Rear): 25 x 8.5 – 14 / 41 x 14 – 20
Weight
- Total Weight (without ballast): 2,870 lbs
| Width |
Weight |
Height |
Length |
| 54 Inch |
2870 Pounds |
88 Inch |
121 Inch |
