Description:

The MT225E Series is a high-value and feature rich compact utility tractor. Featuring high-capacity front-loader and three-point hitch is only the start of what this tractor series provides. Additional deluxe features like an electric engaged Independent PTO come standard.

Specifications:

Engine

• Type: 3 Cylinder, Liquid-Cooled Diesel, Naturally Aspirated, Indirect Injection (IDI)
• Model (Tier 4): Mitsubishi S3L2
• Gross Engine HP: 24.6
• PTO HP: 19.2
• Rated Speed (RPM): 2,500
• Displacement (cu. in.): 80.4
• Fuel Tank Capacity: 7.4 gallons
• Alternator (V-A): 12V – 50 Amps

Drive Train

• Transmission Type: Synchro Shuttle
• Number of Speeds: 12 Forward x 12 Reverse
• Brakes: Wet, Multi-Disc
• Steering: Hydrostatic Power Steering

PTO (Power Take-Off)

• Type: Independent
• Rear PTO Speed: 540 rpm (Standard)

Hydraulic System

• Control System: Position
• Implement Pump Flow (gpm): 7.9
• Steering Pump Flow (gpm): 4.6
• Total Flow (gpm): 12.5
• 3-Point Hitch Category: CAT I
• Hitch Lift Capacity (lbs.): 1,808
• Remote Valves: Optional

Dimensions

• Overall Length (Frame to Link) (in.): 118
• Wheelbase (in.): 66
• Overall Width with Tires (in.): 54
• Height to Top of ROPS (in.): 88

Tire Sizes

• Agricultural Tires (Front / Rear): 7 – 14 / 11.2 – 24
• Industrial Tires (Front / Rear): 25 x 8.5 – 14 / 43 x 16 – 20
• Turf Tires (Front / Rear): 25 x 8.5 – 14 / 41 x 14 – 20

Weight

• Total Weight (without ballast): 2,434 lbs
