Description:
The Bad Boy 30 Series Tractor is the perfect mix of performance and strength. It's riding on a steel frame and cast iron axles, and driven by a powerful 25-horsepower engine. The hydraulics offer class-leading lifting power up to 1314 lbs., far more than other tractors this size.
In terms of pulling power, this Bad Boy features differential lock, automatically equalizing power to both rear wheels. If you need even more boost, use the selectable 4-wheel drive to engage the front wheels and maximize traction and pulling power. And we put all that power at your command with our easy-to-read digital control display. Now you operate anything from the PTO to the front loader, right at your fingertips. The 3026 gets the job done, with strength, convenience and lifting power, all in one compact package.
The Bad Boy 3026 Tractor is built to deliver the same power, strength and quality Bad Boy is known for. It's the perfect size for any farm, ranch, property or outdoor business, delivering the best compact performance. This Bad Boy is all working dog, constructed with a longer frame, larger tires and higher ground clearance so it can handle jobs of any size. And it's made with Bad Boy steel, so there's no job too tough. Plus it features the same Hydro Max Transmission as its larger cousins, the 4035 and 4025 Tractors, giving you the power to automatically increase engine RPMs evenly with the push of a pedal. If you want value, the 3026 delivers, outperforming everything else in its class.
Features:
- 25 Horsepower
- 1,314 lbs. Loader Lift Capacity At Pins
- Hydro Max Transmission
- Dual HST Pedals
- Cast Iron Axles
- Additional Features:
- Reverse Mount Engine
- 3 Range Transmission
- Power Steering
- Selectable 4WD
- Differential Lock
- 6 Year Powertrain Warranty
Specifications:
Engine
-
Type: 3 Cylinder, Water-Cooled, Diesel
-
Horsepower: 25 HP @ rated RPM
-
Displacement: 71.7 in³
-
Cylinders: 3
-
Fuel Tank Capacity: 6.0 gallons
Drivetrain
-
Transmission: HST (Hydrostatic Transmission)
-
Number of Speeds: 3 Range
-
Clutch: Dry Single Plate
-
Brakes: Wet, Multi-Disc
Hydraulics
-
Type: Power Assisted Hydro-Static
-
Total Hydraulic Flow: 7.4 GPM (3.1 GPM steering + 4.3 GPM implement)
-
3-Point Hitch: Category 1
-
Rear Remote Valve: Optional (Up to 1)
-
Lift Capacity @ 24" Behind Lift Point: 974 lbs
Dimensions
-
Overall Length: 110"
-
Overall Width: 53.8"
-
Overall Height: 91.4"
-
Wheelbase: 65.7"
-
Minimum Ground Clearance: 16.4"
-
Weight: 2,106 lbs
PTO
-
Type: Live
-
Speed (Rear/Mid): 540 / 960 RPM
-
PTO Horsepower: 18 HP
Electrical
-
Battery: 12 V, 540 CCA
-
Alternator: 12 V, 50 A
Wheels & Tires
-
Front (IND): 25x8.50-14
-
Rear (IND): 14x17.5
Loader - Model BBL300
-
Standard Bucket Size: 54"
-
Maximum Lift Height: 86"
-
Dig Depth: 4.2"
-
Lift Capacity at Full Height (Pivot Pin): 1,314 lbs
-
Breakout Force: 1,960 lbs
-
Shipping Weight: 654 lbs
Backhoe - Model BBH200
-
Bucket Size: 12"
-
Type: Subframe-Mounted, Quick Attach
-
Maximum Dig Depth: 76"
-
Dig Force (Bucket): 2,050 lbs
-
Shipping Weight: 827 lbs
Width |
Weight |
Height |
Length |
53.8 Inch |
2106 Pounds |
91.4 Inch |
110 Inch |
